The QC Type Overhead Crane with Magnet is a special bridge crane designed for handling magnetically conductive ferrous metal materials, with a lifting capacity range of 5-50/10T. Equipped with an electromagnetic disk, it can quickly lift and release steel plates, billets, profile steel, steel ingots, pig iron blocks, and scrap steel. It is widely used in steel rolling lines, finished product warehouses, shipyard steel yards, metal warehouses, and cutting workshops. The rated capacity includes the magnet dead weight, and the cab position and entrance direction can be selected according to site layout.
Product Features：
1. Designed for Magnetic Metal Handling
The QC overhead crane with magnet is suitable for loading, unloading, stacking, and transferring magnetically conductive ferrous metal materials such as steel plates, billets, profile steel, steel ingots, pig iron blocks, and scrap steel.
2. Higher Efficiency with Electromagnetic Lifting
The electromagnetic disk lifts materials directly without manual sling binding, improving handling efficiency and reducing labor intensity.
3. Suitable for Steel and Metal Processing Industries
It is widely used in steel rolling lines, finished product warehouses, shipyard steel yards, cutting workshops, metal warehouses, and scrap yards.
4. Rated Capacity Includes Magnet Dead Weight
According to the catalog, the rated lifting capacity includes the dead weight of the electromagnetic disk. Both material weight and magnet weight should be considered during selection.
5. Flexible Cabin Arrangement
The cab can be installed on the left or right side, and the platform entrance can be arranged from the side, end, or top to suit different workshop layouts.
6. Customizable Magnet Configuration
Different magnet sizes and quantities can be configured according to the shape, size, weight, and stacking method of the handled materials.
Technical Specifications：
| Parameter | Specification |
|---|---|
| Product Name | QC Type Overhead Crane with Magnet |
| Crane Type | Electromagnetic Overhead Crane |
| Lifting Capacity | 5-50/10T |
| Lifting Device | Electromagnetic Disk / Magnet |
| Suitable Materials | Steel Plate, Billet, Profile Steel, Steel Ingot, Pig Iron, Scrap Steel |
| Cab Position | Left or Right Side Optional |
| Cab Entry Direction | Side Entry / End Entry / Top Entry |
| Rated Capacity | Includes Electromagnetic Disk Dead Weight |
| Crane Total Weight | Excludes Electromagnetic Disk and Auxiliary Facilities |
| Operation Method | Cabin Control / Customized |
| Application | Steel Plant, Rolling Line, Warehouse, Shipyard, Cutting Workshop |
| Customization | Capacity, Span, Lifting Height, Magnet Size, Control System |
Available Capacity Range：
| Model | Capacity |
|---|---|
| QC Overhead Crane with Magnet | 5t |
| QC Overhead Crane with Magnet | 10t |
| QC Overhead Crane with Magnet | 16/3.2t |
| QC Overhead Crane with Magnet | 20/5t |
| QC Overhead Crane with Magnet | 32/5t |
| QC Overhead Crane with Magnet | 50/10t |
The QC Type Overhead Crane with Magnet is a bridge crane equipped with an electromagnetic lifting device. It is mainly used for handling magnetically conductive ferrous metal materials, such as steel plates, billets, profile steel, steel ingots, pig iron blocks, scrap steel, and other metal products. It is widely used in steel plants, rolling mills, finished product warehouses, metal material warehouses, scrap yards, shipyard steel storage yards, and cutting workshops.
According to the catalog, the cab platform entrance can be arranged from the side, end, or top. The cab can be installed on either the left or right side. The rated lifting capacity includes the dead weight of the electromagnetic disk, while the total crane weight does not include the dead weight of the electromagnetic disk and its auxiliary facilities.
Compared with ordinary overhead cranes with hooks, the QC overhead crane with magnet does not require slings or clamps for handling steel materials. It can quickly lift and release metal materials through the electromagnetic disk, improving the efficiency of steel loading, unloading, stacking, and transfer operations. It is suitable for industrial applications requiring frequent handling of steel plates, billets, profiles, and scrap steel.
