The Over Length Electromagnetic Overhead Crane with Carrier-beam is a special bridge crane designed for long steel material handling. Equipped with an over-length electromagnetic carrier-beam, it is suitable for fixed-span areas in steel mills, shipyards, ports, storage yards, and warehouses, both indoors and outdoors. It is especially suitable for handling medium-thick steel plates with width ≤ 3500mm and length ≤ 43000mm. The magnetic force can be adjusted according to material specifications and weight, and different carrier-beam lengths, speed regulation, overload warning, remote control, PLC control, failure detection, and display systems are available.
Product Features：
1. Over-length Electromagnetic Carrier-beam
The crane is equipped with an over-length electromagnetic carrier-beam that can hold multiple electromagnets for multi-point lifting of long steel plates and profiles.
2. Suitable for Long Steel Plate Handling
It is especially suitable for handling medium-thick steel plates with width ≤ 3500mm and length ≤ 43000mm, as well as long plates, large steel sections, and profiles.
3. Adjustable Magnetic Force
The magnetic force of the electromagnets can be adjusted according to the specifications and weight of the lifted material, improving adaptability and safety.
4. Wide Application Range
It can be used in fixed-span areas of steel mills, shipyards, ports, yards, and warehouses, both indoors and outdoors, for loading, unloading, transferring, and stacking operations.
5. Customized Carrier-beam Length
Different carrier-beam lengths can be supplied according to material length, workshop span, stacking method, and handling process.
6. Speed Regulation Available
Each mechanism can be equipped with speed regulation according to user requirements, with a speed ratio of 1:10 or larger, suitable for smooth operation and accurate positioning.
7. Optional Intelligent and Safety Systems
Overload warning, remote control, PLC control, failure detection, and display systems can be provided to improve automation and operational safety.
Technical Specifications：
| Parameter | Specification |
|---|---|
| Product Name | Over Length Electromagnetic Overhead Crane with Carrier-beam |
| Crane Type | Electromagnetic Overhead Crane with Carrier-beam |
| Lifting Device | Over-length Electromagnetic Carrier-beam |
| Suitable Materials | Steel Plate, Profile Steel, Billet, Long Steel Materials |
| Applicable Plate Size | Width ≤ 3500mm, Length ≤ 43000mm |
| Working Site | Steel Mill, Shipyard, Port, Storage Yard, Warehouse |
| Working Environment | Indoor or Outdoor Fixed-span Area |
| Magnetic Force | Adjustable According to Material Specification and Weight |
| Carrier-beam Length | Customized |
| Speed Regulation | 1:10 or Larger Available |
| Safety System | Overload and Warning System |
| Control System | Remote Control / PLC Control Optional |
| Detection System | Failure Detection and Display System Optional |
| Customization | Capacity, Span, Beam Length, Magnet Quantity, Speed Control, Electrical System |
Available Capacity Range：
| Model | Capacity |
|---|---|
| Over Length Electromagnetic Overhead Crane with Carrier-beam | Customized according to plate size and material weight |
| Over Length Electromagnetic Overhead Crane with Carrier-beam | Suitable for steel plates up to 3500mm wide and 43000mm long |
The Over Length Electromagnetic Overhead Crane with Carrier-beam is a special bridge crane equipped with an over-length electromagnetic carrier-beam. It is mainly used in fixed-span areas of steel mills, shipyards, ports, storage yards, and warehouses, both indoors and outdoors. It is suitable for loading, unloading, and transporting steel plates, profile steel, billets, and other long steel materials.
This crane is especially suitable for handling medium-thick steel plates. According to the catalog, it is applicable for steel plates with width ≤ 3500mm and length ≤ 43000mm. The magnetic force of the electromagnet can be adjusted according to the specifications and weight of the lifted material, improving lifting stability and operational safety during long steel plate handling.
Compared with ordinary electromagnetic overhead cranes, this crane uses an over-length carrier-beam with multiple electromagnets to achieve multi-point lifting of long steel plates, reducing the risk of plate deformation, eccentric loading, and swaying. It is ideal for loading, transferring, and stacking long plates, wide plates, and large profile steel.
The catalog also states that different carrier-beam lengths, mechanism speed regulation, magnetic force adjustment, overload warning, remote control, PLC control, failure detection, and display systems can be supplied according to user requirements. The listed technical data is for indoor use.
